COMMSCOPE 12 CPRE MULTIMODE AMOURED OUTDOOR FIBER CABLE OM3 (2121112-3)
Feature | Description |
|---|---|
Fiber Core Count | 6-Core Multimode Fiber – Supports high-speed data transmission |
Standard | OM3 – Optimized for 10Gbps and higher bandwidth applications |
Design | Armored – Provides enhanced durability for outdoor installations |
Protection | Superior resistance to environmental factors – Ensures long-lasting performance |
Brand Quality | CommScope – Trusted brand for reliable fiber optic connectivity solutions |
Feature | Details |
|---|
Manufacturer | CommScope |
Model Number | 2121112-3 |
Fiber Type | Multimode Fiber (OM3) |
Core Count | 12 Cores |
Armoring Type | Armoured (provides enhanced protection against mechanical stress, rodent damage, and environmental hazards) |
Cable Jacket Material | PE (Polyethylene), UV-resistant, designed for outdoor use |
Jacket Color | Black |
Cable Construction | Tight-buffered structure with steel armoring for rugged applications |
Cable Type | Outdoor-rated, Armoured Fiber Optic Cable |
Fiber Grade | OM3 (Optimized for 10Gbps over 300 meters, capable of supporting higher bandwidths for data-intensive applications) |
Applications | Ideal for long-distance outdoor installations, metropolitan area networks (MAN), industrial environments, and data centers |
Bandwidth Support | Up to 2000 MHz·km |
Compliance Standards | Compliant with international performance and safety standards for fiber optics |
Crush Resistance | Designed for high mechanical strength to withstand compression forces and impacts |
Tensile Strength | Engineered to handle higher pull forces during installations |
Moisture Resistance | Fully water-blocked construction with protective inner and outer layers |
UV Resistance | Resistant to UV radiation for outdoor applications |
Operating Temperature | Typically -40°C to +70°C |
Connector Compatibility | Suitable for termination with SC, LC, ST, or other compatible multimode fiber connectors |
Weight | Heavier than non-armoured cables due to additional protective layers |
Usage | Suitable for critical data transmission in telecommunications, broadband networks, and enterprise IT infrastructures |
