D-Link LC-LC mm Patch Cord(NCB-FM50D-LCLC-3)
LC to LC Duplex: Connects two LC fiber optic ports with duplex configuration for bidirectional data transmission
Multimode (MM) Fiber: Optimized for multimode fiber, ensuring reliable and high-speed data transfer
3 Meter Length: Perfect for medium-range fiber optic connections in network environments
Durable & Reliable: Designed for stable, long-lasting performance in fiber optic networking applications
Feature | Description |
|---|---|
Model | D-Link NCB-FM50D-LCLC-3 |
Type | LC-LC Multi-Mode Fiber Patch Cord |
Fiber Type | Multi-Mode (MM) Fiber |
Cable Length | 3 meters |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 50/125 µm (microns) |
Wavelength | 850 nm |
Fiber Mode | OM2/OM3 Fiber (high-performance multi-mode fiber for networking applications) |
Operating Bandwidth | - OM2: 500 MHz·km at 850 nm - OM3: 2000 MHz·km at 850 nm |
Transmission Distance (at 10Gbps) | - OM2: up to 82 meters - OM3: up to 300 meters |
Jacket Material | LSZH (Low Smoke Zero Halogen) material for enhanced safety by reducing smoke and harmful fumes in case of fire |
Connector Material | Ceramic Ferrules for low insertion loss and reliable connection |
Applications | - Ideal for high-speed networking, telecommunications, data centers, and fiber optic connections for servers, switches, and routers |
Weight | 0.2 kg (0.44 lbs) |
Dimensions (H x W x D) | 3.0 mm outer diameter cable |
Color | Aqua color to indicate OM3 Multi-Mode Fiber |
Durability | - Highly durable for long-term use in network environments - Resistant to bending and mechanical stress |
Insertion Loss | Low insertion loss for minimal signal degradation and improved network efficiency |
Flexibility | Flexible for easy installation in tight spaces and routing through high-density fiber optic networks |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) for easy and consistent fiber optic connections |
Warranty | 1-Year Limited Warranty |
Additional Features | - Designed for high-performance data transmission in 10GbE, Gigabit Ethernet, and other high-speed networks - Provides reliable, efficient fiber optic connectivity |
