D-Link Lc-Lc OM3 Fiber Patch Cord (NCB-FM53D-LCLC-3 (Cent)

Model

D-Link NCB-FM53D-LCLC-3 (Cent)

Type

LC-LC Multi-Mode OM3 Fiber Patch Cord

Fiber Type

Multi-Mode (MM) Fiber

Cable Length

3 meters

Connector Type

LC to LC Duplex Fiber Optic Connectors

Core Diameter

50/125 µm (microns)

Wavelength

850 nm

Fiber Mode

OM3 Fiber (designed for higher-speed and long-distance multi-mode applications)

Operating Bandwidth

2000 MHz·km at 850 nm, suitable for high-speed and long-distance transmission in high-performance networks

Transmission Distance (at 10Gbps)

Up to 300 meters

Jacket Material

LSZH (Low Smoke Zero Halogen) material for increased safety by minimizing smoke and toxic fumes in case of fire

Connector Material

Ceramic Ferrules for low insertion loss and high-performance, stable connections

Applications

- Ideal for high-speed networking, data centers, telecommunications, and fiber optic networks

Weight

0.2 kg (0.44 lbs)

Dimensions (H x W x D)

Typically 3.0 mm outer diameter cable

Color

Aqua color to signify OM3 Multi-Mode Fiber

Durability

- High durability for long-term network use - Resistant to mechanical stress and bending, designed to withstand harsh environments

Insertion Loss

Low insertion loss for minimal signal degradation, ensuring efficient data transmission

Flexibility

Flexible design for easy installation in tight spaces and complex routing environments

Compliance

- RoHS Compliant - CE Certified

Connector Polarity

Straight-through (LC to LC) for consistent and reliable fiber optic connectivity

Warranty

1-Year Limited Warranty

Additional Features

- Designed for high-speed data transmission in 10GbE, Gigabit Ethernet, and other high-performance networks - Ensures reliable, efficient connectivity over long distances
