D-Link Lc-Lc OM3 Fiber Patch Cord (NCB-FM53D-LCLC-3 (Cent)
LC to LC Duplex: Connects two LC fiber optic ports with duplex configuration for bidirectional data transmission
OM3 Multimode Fiber: Provides high-speed data transfer with enhanced bandwidth over medium distances, ideal for modern network setups
3 Meter Length: Suitable for medium-range fiber optic connections in enterprise or data center environments
Centum Series: Part of D-Link's Centum series, offering reliable and high-performance fiber optic solutions for networking needs
Feature | Description |
|---|---|
Model | D-Link NCB-FM53D-LCLC-3 (Cent) |
Type | LC-LC Multi-Mode OM3 Fiber Patch Cord |
Fiber Type | Multi-Mode (MM) Fiber |
Cable Length | 3 meters |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 50/125 µm (microns) |
Wavelength | 850 nm |
Fiber Mode | OM3 Fiber (designed for higher-speed and long-distance multi-mode applications) |
Operating Bandwidth | 2000 MHz·km at 850 nm, suitable for high-speed and long-distance transmission in high-performance networks |
Transmission Distance (at 10Gbps) | Up to 300 meters |
Jacket Material | LSZH (Low Smoke Zero Halogen) material for increased safety by minimizing smoke and toxic fumes in case of fire |
Connector Material | Ceramic Ferrules for low insertion loss and high-performance, stable connections |
Applications | - Ideal for high-speed networking, data centers, telecommunications, and fiber optic networks |
Weight | 0.2 kg (0.44 lbs) |
Dimensions (H x W x D) | Typically 3.0 mm outer diameter cable |
Color | Aqua color to signify OM3 Multi-Mode Fiber |
Durability | - High durability for long-term network use - Resistant to mechanical stress and bending, designed to withstand harsh environments |
Insertion Loss | Low insertion loss for minimal signal degradation, ensuring efficient data transmission |
Flexibility | Flexible design for easy installation in tight spaces and complex routing environments |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) for consistent and reliable fiber optic connectivity |
Warranty | 1-Year Limited Warranty |
Additional Features | - Designed for high-speed data transmission in 10GbE, Gigabit Ethernet, and other high-performance networks - Ensures reliable, efficient connectivity over long distances |
