TP-Link AC1200 Mesh Wi-Fi Range Extender-RE305

Working Modes

Range Extender / Access Point

Standards & Protocols

IEEE 802.11a/b/g/n/ac

Plug Types

EU, UK, US

Interface

1 x 10/100Mbps Ethernet Port (RJ45)

Buttons

WPS Button, Reset Button

Input Power

100-240V~ 50/60Hz

Max Power Consumption

7.3W (max)

Dimensions (W x D x H)

80 x 78 x 77 mm (3.1 x 3.0 x 3.0 in.)

Antenna

2 x external

Wireless Standards

2.4GHz: IEEE 802.11b/g/n, 5GHz: IEEE 802.11a/n/ac

Frequency Bands

2.4GHz & 5GHz

Signal Rate

2.4GHz: Up to 300Mbps, 5GHz: Up to 867Mbps

Reception Sensitivity

2.4GHz: Up to -79dBm, 5GHz: Up to -91dBm (varies by rate)

Wireless Modes

Range Extender / Access Point

Wireless Functions

Concurrent Dual Band, Access Control, LED Control, Domain Login, Stats

Wireless Security

64/128-bit WEP, WPA-PSK / WPA2-PSK

Transmission Power

<17dBm (2.4GHz & 5GHz)

Mesh Technology

EasyMesh-Compatible
