Transcend's PCIe M.2 SSDs -TS128GMTE470A
The Transcend TS128GMTE470A is a high-performance PCIe Gen3 x4 M.2 2242 NVMe SSD with a capacity of 128GB, built with 112-layer 3D NAND flash. It offers fast sequential read speeds of up to 2000MB/s and write speeds of up to 1700MB/s, designed for industrial and mobile computing applications.
Model: TS128GMTE470A
Type: Internal M.2 2242 SSD
Interface: PCIe Gen 3 x4, NVMe 1.4 compliant
NAND Type: 112-layer 3D NAND flash
Capacity: 128GB
Sequential Read Speed: Up to 2000 MB/s
Sequential Write Speed: Up to 1700 MB/s
Random Read IOPS: Up to 105,000
Random Write IOPS: Up to 275,000
Form Factor: M.2 2242 (22mm width x 42mm length x 2.23mm height)
Operating Voltage: 3.3V ± 5%
Operating Temperature Range: -20°C to 75°C (standard), extended -40°C to 85°C optional
Wide Temperature Version Available for harsh environments
Hardware encryption with AES 256-bit, compliant with TCG Opal 2.0 standards
Durability: Rated for up to 3000 P/E cycles, with Power Shield technology to prevent data corruption during power loss
General
- Type Of Hard DiskSSD
- Connectivity TechnologyNVME
- Connection TypePCI Express x4
- Compatible DevicesLaptop & Desktop
Storage
- SizeUp to 120 GB
- Digital Storage Capacity128 GB
