TP-Link 5-Port Gigabit Desktop Switch with 4-Port PoE+(LS105GP)
Key Point | Description |
|---|---|
Gigabit Ports | Five gigabit auto-negotiation ports with up to 10 Gbps switching capacity. |
PoE Budget | 65 W PoE budget with 4 gigabit 802.3af/at PoE+ ports, 30 W per port. |
PoE Transmission Range | Up to 250m PoE transmission with Extend Mode for large area surveillance. |
PoE Auto Recovery | Automatically reboots dropped or unresponsive PoE-powered devices. |
Silent Operation | Fanless design for reduced power consumption and silent operation. |
Category | Details |
|---|---|
Interface | 5× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 support 802.3af/at PoE+), Auto Negotiation, Auto MDI/MDIX |
Network Media | 10BASE-T: UTP Cat 3, 4, 5 (Max 100m); 100BASE-TX: UTP Cat 5, 5e (Max 100m); 1000BASE-T: UTP Cat 5, 5e, 6 (Max 100m) |
Fan Quantity | Fanless |
Installation | Desktop, Wall Mounting |
Power Supply | External Power Adapter (Output: 53.5 VDC / 1.31 A) |
PoE Ports (RJ45) | 802.3 af/at compliant, Ports 1–4, up to 30 W PoE output per port, Power Supply: 65 W |
Dimensions (W x D x H) | 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm) |
Max Power Consumption | 4 W (No PD connected, 220/50 Hz), 74.46 W (With 65 W PD connected, 220/50 Hz) |
Max Heat Dissipation | 13.6 BTU/h (No PD connected), 253.16 BTU/h (With 65 W PD connected) |
Switching Capacity | 10 Gbps |
Packet Forwarding Rate | 7.44 Mpps |
MAC Address Table | 2K |
Jumbo Frame | 16 KB |
Advanced Features | Extend Mode (Up to 250m PoE), PoE Auto Recovery, Compatible with IEEE 802.3af/at PDs, Mac Address Auto-Learning and Auto-Aging |
Transmission Method | Store-and-Forward |
Software Features | IEEE 802.3x Flow Control, 802.1p/DSCP QoS, IGMP Snooping, Green Technology |
General
- TypesUnManaged
- Switching Capacity10 Gbit/s
- Port TypeRJ45
- No. Of RJ45 Ports5
- No. Of Power Supplies Supported1
- Rack MountingNo
