TP-Link 24-Port Gigabit Easy Smart Switch-TL-SG1024DE

Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p

Interface

24 10/100/1000Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (max 100m), 100BASE-TX: UTP category 5, 5e cable (max 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (max 100m)

Fan Quantity

Fanless

Physical Security Lock

No

Power Supply

100-240VAC, 50/60Hz

Dimensions (W x D x H)

11.6 × 7.1 × 1.7 in (294 × 140 × 44 mm)

Mounting

Rack Mountable

Max. Power Consumption

13.66W (220V/50Hz)

Max Heat Dissipation

46.58 BTU/h

Switching Capacity

48Gbps

Packet Forwarding Rate

35.7Mpps

MAC Address Table

8K

Packet Buffer Memory

4.1Mbit

Jumbo Frame

10KB

Quality of Service

Port-based/802.1p/DSCP priority, 4 priority queues, Rate Limit, Storm Control

L2 Features

IGMP Snooping V1/V2/V3, Static Link Aggregation, Port Mirroring, Cable Diagnostics, Loop Prevention

VLAN

Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs), MTU/Port/Tag VLAN

Transmission Method

Store-And-Forward

Certification

FCC, CE, RoHS

Package Content

TL-SG1024DE, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet

System Requirements

Microsoft® Windows® for running Utility

Operating Temperature

0℃~40℃ (32℉~104℉)

Storage Temperature

-40℃~70℃ (-40℉~158℉)

Operating Humidity

10%~90% non-condensing

Storage Humidity

5%~90% non-condensing
