Cisco Meraki 8 port switch -MS130-8
Feature | Description |
|---|---|
PoE+ Support | Available with 120 W PoE+ power budget |
High-Speed Uplinks | Optional 2× 2.5 GbE mGig and 2× 10G SFP+ ports |
Silent Operation | Fanless design for quiet environments |
Scalable & Future-Ready | Centralized management and Adaptive Policy support with future firmware update |
Specification | Details |
|---|---|
1GbE RJ45 Ports | 8 |
mGbE RJ45 Ports | — |
1GbE SFP Ports | 2 |
10GbE SFP+ Ports | — |
Dedicated Management Interface | — |
PoE/PoE+ Capable | — |
Power Input | 12VDC, 2.5A |
Power Load (Idle/Max) | 8W / 8W |
Power Consumption Range | 8 - 808W |
Operating Temperature | 32°F - 113°F / 0°C - 45°C |
Storage/Transportation Temperature | -4°F - 158°F / -20°C - 70°C |
Humidity Tolerance | 5% to 95% |
Mounting Options | Desktop, Integrated Wall Mount |
Switching Capacity | 20 Gbps |
Power Supply | External |
Fan Operation | Fanless |
Dimensions (H x W x D) | 1.1 x 8.74 x 6 in / 2.8 x 22.2 x 15 cm |
Weight | 1.94 lb / 0.88 kg |
What's in the Box | MS130 switch, AC Power Supply |
General
- Switching Capacity20 Gbit/s
- Port TypeRJ45
- No. Of SFP Ports2
- No. Of RJ45 Ports8
- No. Of Power Supplies Supported1
- Rack MountingYes
