D-Link LC-LC SM Fiber Patch Cord 3Mtr (NCB-FS09D-LCLC-3-LS)
LC to LC Duplex: Connects two LC fiber optic ports with duplex configuration for bidirectional data transfer
Singlemode (SM) Fiber: Designed for long-distance, high-speed data transmission with low signal attenuation
3 Meter Length: Suitable for short to medium-range fiber optic connections in network environments
Low Smoke (LS) Construction: Features low smoke zero halogen (LSZH) jacket for safer use in confined spaces or environments requiring reduced emissions in case of fire
Feature | Description |
|---|---|
Model | D-Link NCB-FS09D-LCLC-3-LS |
Type | LC-LC Single-Mode Fiber Patch Cord |
Fiber Type | Single-Mode (SM) Fiber |
Cable Length | 3 meters |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 9/125 µm (microns) |
Wavelength | 1310 nm / 1550 nm |
Fiber Mode | Single-Mode (SM) Fiber (designed for long-distance, high-speed, and high-bandwidth applications) |
Operating Bandwidth | 100 MHz·km at 1310 nm, ideal for high-performance, long-range data transmission |
Transmission Distance (at 10Gbps) | Up to 40 kilometers |
Jacket Material | LSZH (Low Smoke Zero Halogen) material for enhanced safety by reducing smoke and harmful gases in case of fire |
Connector Material | Ceramic Ferrules for low insertion loss and secure, reliable connections |
Applications | - Ideal for long-distance networking, data centers, telecommunications, high-performance fiber optic networks |
Weight | 0.18 kg (0.39 lbs) |
Dimensions (H x W x D) | Typically 3.0 mm outer diameter cable |
Color | Yellow color to signify Single-Mode Fiber |
Durability | - High durability for reliable use in challenging environments - Resistant to bending and mechanical stress, ensuring long-term stability in network installations |
Insertion Loss | Low insertion loss for optimal signal integrity and efficient data transmission |
Flexibility | Flexible for installation in tight spaces and through complex network routing |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) for consistent, reliable fiber optic connections |
Warranty | 1-Year Limited Warranty |
Additional Features | - Optimized for long-range, high-speed applications such as 10GbE, Gigabit Ethernet, and telecommunications networks - Ensures reliable, efficient data transmission |
