DIGISOL L3 Intelligent Switch with 10G Uplink, DG-GS4930SE

Technical Specifications – DG-GS4930SE

Physical Specifications

• Ports:

  • 24 × 10/100/1000Base-T

  • 6 × 10G SFP+

  • Auto-MIDX

• Management Interfaces:

  • 1 × RJ45 Ethernet Management Port

  • 1 × Console Port

  • 1 × USB 2.0 Interface

Performance

• Switching Capacity: 168 Gbps

• Forwarding Rate: 125 Mpps

• Jumbo Frame Support: 12K

• MAC Address Table: 32K

• ARP Table: 8K

• Routing Table: 12K

• ACL Table: 4K

Physical & Environmental

• Dimensions (W × H × D): 44 cm × 4.4 cm × 38 cm

• Relative Humidity: 5% – 95% (non-condensing)

• Temperature Range:

  • Operating: 0°C to 50°C

  • Storage: -40°C to 70°C

• Power Supply: AC 100 – 240V, 50 – 60Hz

• Power Consumption: < 45W

Layer 1 & Layer 2 Features

• IEEE 802.3 Standards:

  • IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3z (1000BASE-X), IEEE 802.3ab (1000Base-T)

  • IEEE 802.3ae (10GBase), IEEE 802.3x, IEEE 802.3ak (10GBASE-CX4)

• Loopback Detection

• Link Layer Discovery Protocol (LLDP & LLDP-MED), UDLD

• LACP (802.3ad) Support:

  • Supports up to 128 group trunks with a maximum of 8 ports per trunk

  • LACP Load Balancing

• Network Redundancy & Protection:

  • ERPS (G.8032)

  • N:1 Port Mirroring

  • RSPAN

  • Spanning Tree Protocols: IEEE 802.1d (STP), IEEE 802.1w (RSTP), IEEE 802.1s (MSTP)

  • Root Guard, BPDU Guard, BPDU Tunnel

• VLAN Support:

  • 802.1Q (4K VLANs)

  • MAC VLAN, Voice VLAN, PVLAN, Protocol VLAN, Multicast VLAN

  • QinQ, Flexible QinQ

  • GVRP

  • N:1 VLAN Translation

• Traffic & Security Features:

  • Broadcast/Multicast/Unicast Storm Control

  • IGMP Snooping (v1/v2/v3) with L2 Query

  • ND Snooping, MLDv1/v2 Snooping

  • Port Security

  • Flow Control: HOL, IEEE 802.3x

  • Bandwidth Control

Layer 3 Features

• Routing Protocols:

  • Static Routing, RIPv1/v2, IS-IS, OSPFv2, BGP4

  • OSPFv3, BGP4+

  • OSPF Multiple Processes

• Advanced Routing Capabilities:

  • VRF-Lite

  • LPM Routing

  • Policy-Based Routing (PBR) for IPv4 & IPv6

  • VRRP, URPF, ECMP, BFD

• Multicast Routing:

  • IGMP v1/v2/v3, IGMP Proxy

  • Static Multicast Route

  • Multicast Receive Control

  • Illegal Multicast Source Detection

• ARP & Security:

  • ARP Guard, Local ARP Proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit

  • Anti-ARP Cheat, Anti-ARP Scan

• Tunneling Support:

  • GRE Tunnel

  • IPv6 6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE Tunnel

• IPv6 Features:

  • ICMPv6, ND, DNSv6

  • IPv6 LPM Routing, IPv6 PBR

  • IPv6 VRRPv3, IPv6 URPF, IPv6 RA

  • RIPng, OSPFv3, BGP4+

  • MLD Snooping, IPv6 Multicast VLAN

  • IPv6 Anycast RP, IPv6 ACL, IPv6 QoS

Quality of Service (QoS)

• Queue Management:

  • 8 Queues

  • SP, WRR, SP+WRR

  • WRED

• Traffic Classification:

  • Based on 802.1p COS, ToS, DiffServ DSCP, ACL, Port Number

• Traffic Policing & Prioritization:

  • PRI Mark/Remark

Access Control Lists (ACLs)

• Types of ACLs:

  • IP ACL

  • MAC ACL

  • IP-MAC ACL

• Filters & Rules:

  • Based on source/destination IP or MAC, IP Protocol, TCP/UDP Port, DSCP, ToS, IP Precedence, VLAN, Tag/Untag, CoS

  • Redirect & Statistics

  • Configurable to Port, VLAN, VLAN Routing Interfaces

  • Time-Ranged ACL

Security Features

• Authentication & Access Control:

  • 802.1x AAA, Port & MAC-Based Authentication

  • Accounting based on time length & traffic

  • Guest VLAN & Auto VLAN

  • RADIUS & TACACS+ for IPv4 & IPv6

  • MAB (MAC Authentication Bypass)

• DHCP Security:

  • DHCPv4/v6 Traffic Monitoring

  • DHCP Server/Client for IPv4/IPv6

  • DHCP Relay/Option 82

  • DHCP Snooping/Option 82

Network Management & Monitoring

• Traffic Monitoring:

  • Flow Traffic Analysis

• Management Interfaces:

  • CLI, Web UI, Telnet, SNMPv1/v2c/v3 (IPv4 & IPv6)

  • Syslog & External Syslog Server

  • HTTP SSL

  • SNMP MIB, SNMP TRAP

  • FTP/TFTP

  • SNTP/NTP

  • RMON (1, 2, 3, 9)

• Security Management:

  • Authentication via RADIUS/TACACS+

  • SSH v1/v2

  • Dual Firmware Images & Configuration Files

• OAM Features:

  • 802.3ah OAM, 802.1ag OAM

Data Center Features

• Virtual Switch Framework (VSF): Enables device stacking for increased scalability and simplified network management.

Ordering Information

• DG-GS4930SE-B1: DIGISOL L3 Intelligent Ethernet Switch with 24 × 10/100/1000Base-T + 6 × 10G (SFP+), Single AC power supply (Hot-swappable).

• DG-GS4930SE-B2: DIGISOL L3 Intelligent Ethernet Switch with 24 × 10/100/1000Base-T + 6 × 10G (SFP+), Dual AC power supplies (Hot-swappable).

Note: Warranty is subject to the terms and conditions specified in the DIGISOL PRODUCT WARRANTY displayed on the company website. DIGISOL logos are trademarks of DIGISOL SYSTEMS LIMITED. Product information is subject to change without notice.
