Digisol Enterprise Wireless Access Controller, DG-WU6028C
Key Features
Intelligent Integrated Control and Forwarding Architecture – Ensures seamless data processing and efficient network performance.
Emergency Mechanism for APs – Provides reliable backup and failover solutions for uninterrupted connectivity.
Quality of Service (QoS) – Optimizes bandwidth allocation for enhanced user experience.
RF Management – Effectively regulates radio frequencies to minimize interference and improve signal strength.
Airtime Fairness-Based Terminal Control – Equitably distributes network resources among connected devices.
Load Balancing Mechanism – Distributes network traffic evenly to maintain stable performance.
Category | Specification |
|---|---|
Basic Parameter | |
Max QTY of Managed AP | 256 |
Default QTY of Managed AP | 16 |
Max Concurrent Users | 10K |
Switch Capacity | 364Gbps |
Forwarding Rate | 132Mpps |
VLAN | 4K |
ACL | 3K |
MAC | 16K |
ARP | 4K |
Physical Parameter | |
Interface | 24 x 10/100/1000Base-T Ethernet ports |
2 x Combo (GbE/SFP) Ethernet ports | |
2 x 10G SFP+ Ethernet ports | |
Management Interface | |
1 x Console (RJ-45) | |
1 x 10/100/1000BASE-T MGMT | |
1 x USB 2.0 | |
Dimension | 440mm × 240mm × 44mm, 1U |
Power Parameter | |
Power Consumption | <25W |
Power Input | AC 110V - 240V, 50-60Hz (+/- 3Hz) |
Environmental Parameter | |
Working Temperature | 0℃ ~ 55℃ |
Storage Temperature | -40℃ ~ 70℃ |
Working Humidity | 5% ~ 90% non-condensing |
General
- Ethernet LAN (RJ-45) ports1
