D-Link LC-LC mm Patch Cord 5 Mtr (NCB-FM50D-LCLC-5)
LC to LC Duplex: Connects two LC fiber optic ports with a duplex configuration for bidirectional data transfer
Multimode (MM) Fiber: Provides reliable data transmission over short to medium distances
5 Meter Length: Offers flexibility for mid-range fiber optic connections in network setups
Durable & High-Quality: Designed for stable, long-lasting performance in networking and fiber optic applications
Feature | Description |
|---|---|
Model | D-Link NCB-FM50D-LCLC-5 |
Type | LC-LC Multi-Mode Fiber Patch Cord |
Fiber Type | Multi-Mode (MM) Fiber |
Cable Length | 5 meters |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 50/125 µm (microns) |
Wavelength | 850 nm |
Fiber Mode | OM2/OM3 Fiber (supports high-speed, multi-mode fiber for various network applications) |
Operating Bandwidth | - OM2: 500 MHz·km at 850 nm - OM3: 2000 MHz·km at 850 nm |
Transmission Distance (at 10Gbps) | - OM2: up to 82 meters - OM3: up to 300 meters |
Jacket Material | LSZH (Low Smoke Zero Halogen) material to minimize smoke and harmful gases in case of fire |
Connector Material | Ceramic Ferrules for low insertion loss and high-quality connections |
Applications | - Ideal for networking, telecommunications, data centers, and high-speed multi-mode fiber networks |
Weight | 0.25 kg (0.55 lbs) |
Dimensions (H x W x D) | Typically 3.0 mm outer diameter cable |
Color | Typically Aqua for OM3 Multi-Mode Fiber |
Durability | - High durability for long-lasting, reliable use in various industrial environments - Resistant to mechanical stress and bending |
Insertion Loss | Low insertion loss for minimal signal degradation and improved network performance |
Flexibility | Highly flexible for installation in tight spaces and environments with complex cable routing |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) for easy and reliable fiber optic connections |
Warranty | 1-Year Limited Warranty |
Additional Features | - Ideal for high-performance networking applications, including 10GbE and Gigabit Ethernet - Ensures efficient data transmission and seamless network connectivity |
