TP-Link Omada Pro 48-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP+ Slots-S5500-48GP4XF
Feature | Details |
|---|---|
PoE+ Ports | 48× gigabit 802.3at/af-compliant PoE+ ports with 500 W PoE budget |
Uplink Speed | 4× 10 Gbps SFP+ slots for high-bandwidth connectivity |
Omada Pro Integration | ZTP, anomaly detection, centralized cloud management with Omada App |
Security | ACL, IP-MAC-Port Binding, VLAN Binding, 802.1X, Radius Authentication |
Redundancy & Routing | ERPS, Static Routing for efficient traffic management |
Category | Main Key Points |
|---|
Hardware Features | 48× Gigabit RJ45 Ports (PoE+), 4× 10G SFP+ Slots, PoE+ (802.3at/af), 500W PoE Budget |
Mounting & Size | Rackmountable, 440×330×44 mm |
Power Supply | Internal AC (100~240V, 50/60Hz), Max Power: 635.7W (with PoE devices connected) |
Cooling | 3 Fans |
Performance | 176 Gbps Switching Capacity, 130.94 Mpps Forwarding Rate, 16K MAC Table, 9KB Jumbo Frames |
Protocols Supported | IEEE 802.3/802.1 series (VLAN, STP, LACP, 802.1X, etc.) |
QoS Features | 8 Queues, CoS/DSCP Priority, SP/WRR/SP+WRR Scheduling, Bandwidth Control |
L3 Features | 16 IPv4/IPv6 Interfaces, 48 Static Routes, DHCP Server/Relay, Proxy ARP |
L2 & L2+ Features | LACP (8 groups), STP/RSTP/MSTP, Loop Protection, Port Mirroring, Flow Control |
Multicast Features | IGMP v1–v3 Snooping, MLD v1/v2 Snooping, MVR, Static Multicast Group Config |
Advanced Features | OAM, L2PT, DLDP, QinQ, PPPoE ID, DDM, ERPS, sFlow, Anomaly Detection |
VLAN Support | 4K VLANs, 802.1Q, MAC VLAN, Voice VLAN, Protocol VLAN, QinQ, GVRP |
ACL Support | MAC/IP/IPv6 ACLs, Time-Based ACLs, Actions: Mirror, Redirect, QoS, Rate Limit |
Security | IP-MAC-Port Binding, DHCP Snooping, ARP/ND Inspection, DoS Defense, Port Security |
IPv6 Support | Dual Stack, IPv6 ACLs & Routing, DHCPv6, ND, MLD, Ping6, Traceroute6, SSL, SSH |
General
- TypesManaged
- Switching Capacity176 Gbit/s
- Port TypeRJ45
- No. Of RJ45 Ports48
- No. Of Power Supplies Supported1
- Rack MountingYes
