TP-Link 8-Port 10/100/1000Mbps Desktop Switch-LS108G
Brand | TP-Link |
Number of Ports | 8 |
Included Components | 8-Port 10/100/1000Mbps Desktop Switch, Power Adapter, Installation Guide |
Colour | Blue |
Compatible Devices | Desktop |
Category | Details |
|---|---|
Hardware Features | |
Standards & Protocols | IEEE 802.3i / 802.3u / 802.3ab / 802.3x, IEEE 802.1p |
Interface | 8× 10/100/1000 Mbps Ports (Auto-Negotiation, Auto MDI/MDIX) |
Fan Quantity | Fanless |
External Power Supply | External Power Adapter |
LED Indicators | System Power, Link/Act (per port) |
Dimensions (W × D × H) | 6.2 × 3.9 × 1.0 in (158 × 99.1 × 25 mm) |
Max. Power Consumption | 3.7 W (220V/50Hz) |
Max Heat Dissipation | 12.617 BTU/hr |
Performance | |
Packet Forwarding Rate | 11.9 Mpps |
MAC Address Table | 4K |
Packet Buffer Memory | 1.5 Mb |
Jumbo Frame | 16 KB |
Software Features | |
Advanced Features | Green Technology, 802.3X Flow Control, 802.1P/DSCP QoS |
Transmission Method | Store and Forward |
Others | |
Certification | CE, FCC, RoHS |
Package Contents | 8-Port 10/100/1000Mbps Desktop Switch, Power Adapter, Installation Guide |
General
- TypesUnManaged
- Switching Capacity16 Gbit/s
- Port TypeEthernet
- No. Of Ethernet Ports8
- Rack MountingNo
