TP-Link Load Balance Broadband Router-TL-R470T+

Hardware Features

Standards: IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS

Interface

1 Fixed Ethernet WAN Port, 1 Fixed Ethernet LAN Port, 3 Changeable Ethernet WAN/LAN Ports

Network Media

10BASE-T and 100BASE-TX: UTP Category 3/4/5/5e (max 100m)

Power Supply

External 9V/0.6A DC Adapter

Flash

16MB

DRAM

128MB

LED Indicators

PWR, SYS, WAN, LAN, WAN/LAN

Dimensions

6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)

Performance

Concurrent Sessions: 10,000

WAN Connection Type

Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable

MAC Clone

Modify WAN/LAN MAC Address

DHCP

DHCP Server/Client, DHCP Address Reservation

Switch Settings

Port Mirror, Rate Control, Port Configuration, Port VLAN

Advanced Features

Access Control (IP/MAC/URL/WEB Filtering), IGMP Proxy/Snooping, Virtual Server, Port Triggering, DMZ, Load Balance (Policy Routing, Link Backup)

NAT

One-to-One NAT, Multi-Nets NAT

Routing

Static Routing

Security

FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death, IP/MAC Binding

Traffic Control

Bandwidth Control, Session Limit
