D-Link LC-LC SM Fiber Patch Cord (NCB-FS09D-LCLC-3)-(Cent)
LC to LC Duplex: Connects two LC fiber optic ports with duplex configuration for bidirectional data transmission
Singlemode (SM) Fiber: Optimized for long-distance, high-speed data transfer with low attenuation
3 Meter Length: Suitable for short to medium-range fiber optic connections in networking setups
Centum Series: Part of D-Link's Centum series, ensuring high-performance, reliable fiber optic solutions for enterprise and data center applications
Feature | Description |
|---|---|
Model | D-Link NCB-FS09D-LCLC-3 (Cent) |
Type | LC-LC Single-Mode Fiber Patch Cord |
Fiber Type | Single-Mode (SM) Fiber |
Cable Length | 3 meters |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 9/125 µm (microns) |
Wavelength | 1310 nm / 1550 nm |
Fiber Mode | Single-Mode (SM) Fiber (designed for long-distance, high-speed applications) |
Operating Bandwidth | 100 MHz·km at 1310 nm, optimized for long-distance, high-performance data transmission |
Transmission Distance (at 10Gbps) | Up to 40 kilometers |
Jacket Material | LSZH (Low Smoke Zero Halogen) material for enhanced safety by reducing smoke and toxic fumes during a fire |
Connector Material | Ceramic Ferrules for low insertion loss and consistent, reliable connections |
Applications | - Suitable for long-distance networking, data centers, telecommunications, and high-performance fiber optic networks |
Weight | 0.18 kg (0.39 lbs) |
Dimensions (H x W x D) | Typically 3.0 mm outer diameter cable |
Color | Yellow color to indicate Single-Mode Fiber |
Durability | - Highly durable for long-term network installations - Resistant to bending and mechanical stress, designed for heavy-duty use |
Insertion Loss | Low insertion loss for better signal transmission and efficiency in data transfer |
Flexibility | Flexible for easy routing and installation in tight spaces |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) for reliable and consistent fiber optic connectivity |
Warranty | 1-Year Limited Warranty |
Additional Features | - Suitable for high-speed, long-distance transmission in 10GbE, Gigabit Ethernet, and telecommunications networks - Ensures reliable, efficient connectivity over extended ranges |
