D-Link LC-LC MM Fiber Patch Cord (NCB-FM62D-LCLC-20)-(Cent)
LC to LC Duplex: Connects two LC fiber optic ports with duplex configuration for bidirectional data transfer
Multimode (MM): Optimized for multimode fiber with excellent performance over medium-range distances
20 Meter Length: Ideal for longer connections in network setups, providing flexibility
Centum Series: Part of D-Link's Centum series, offering high-quality and reliable fiber optic solutions for enterprise networks
Feature | Description |
|---|---|
Model | D-Link NCB-FM62D-LCLC-20-(Cent) |
Type | LC-LC Multi-Mode Fiber Patch Cord |
Fiber Type | Multi-Mode (MM) Fiber |
Cable Length | 20 meters |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 50/125 µm (microns) |
Wavelength | 850 nm |
Fiber Mode | OM2/OM3 Fiber (supports OM3 for high-speed applications) |
Operating Bandwidth | Supports 500 MHz·km (OM2) and 2000 MHz·km (OM3) bandwidth at 850 nm wavelength |
Transmission Distance (at 10Gbps) | - OM2: up to 82 meters - OM3: up to 300 meters |
Jacket Material | LSZH (Low Smoke Zero Halogen) material for enhanced safety, reducing smoke and harmful fumes in case of fire |
Connector Material | Ceramic Ferrules for low insertion loss and high-performance, ensuring stable connections |
Applications | - Suitable for high-speed networking, including 10GbE, data centers, telecommunications, and high-performance fiber optic networks |
Weight | 0.45 kg (0.99 lbs) |
Dimensions (H x W x D) | - 3.0mm outer diameter cable |
Color | Aqua color to signify OM3 Multi-Mode Fiber |
Durability | - High durability for long-term network installations - Resistant to mechanical stresses and bending |
Insertion Loss | Low insertion loss for improved signal quality and efficiency |
Flexibility | Designed to handle tight bends and provide flexibility in confined spaces for network setups |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) ensuring easy and direct fiber optic connections |
Warranty | 1-Year Limited Warranty |
Additional Features | - Optimized for high-speed fiber optic networks - Provides reliable fiber optic connectivity for high-density network environments |
