D-Link LC-LC MM OM2 Fiber Patch Cord (NCB-FM50D-LCLC-1)
LC to LC Duplex: Connects two LC fiber optic ports with a duplex configuration for bidirectional data transmission
OM2 Multimode Fiber: Provides reliable data transfer over short to medium distances with high bandwidth
1 Meter Length: Ideal for short-range connections in fiber optic networks
Durable & Efficient: Designed for stable performance and long-lasting use in networking environments
Feature | Description |
|---|---|
Model | D-Link NCB-FM50D-LCLC-1 |
Type | LC-LC Multi-Mode OM2 Fiber Patch Cord |
Fiber Type | Multi-Mode (MM) Fiber |
Cable Length | 1 meter |
Connector Type | LC to LC Duplex Fiber Optic Connectors |
Core Diameter | 50/125 µm (microns) |
Wavelength | 850 nm |
Fiber Mode | OM2 Fiber (supports multi-mode fiber for short to medium-distance applications) |
Operating Bandwidth | 500 MHz·km bandwidth at 850 nm, providing stable data transmission for standard applications |
Transmission Distance (at 10Gbps) | Up to 82 meters |
Jacket Material | LSZH (Low Smoke Zero Halogen) material for increased safety by reducing smoke and toxic emissions in case of fire |
Connector Material | Ceramic Ferrules for low insertion loss and better performance during data transmission |
Applications | - Ideal for short-range high-speed fiber optic connections in networking, telecommunications, data centers, and enterprise networks |
Weight | 0.15 kg (0.33 lbs) |
Dimensions (H x W x D) | 3.0 mm outer diameter cable |
Color | Beige or Aqua color to signify OM2 Multi-Mode Fiber |
Durability | - High durability for reliable, long-lasting performance in network installations - Resistant to mechanical stress and bending |
Insertion Loss | Low insertion loss for reduced signal degradation and improved network efficiency |
Flexibility | Designed with high flexibility to handle tight bends and complex routing for network installations |
Compliance | - RoHS Compliant - CE Certified |
Connector Polarity | Straight-through (LC to LC) for seamless connectivity |
Warranty | 1-Year Limited Warranty |
Additional Features | - Provides reliable and efficient data transmission for short-range fiber optic applications - High performance for 10Gbps Ethernet, Gigabit Ethernet, and more |
