D-Link Cat6 UTP 48 Port Loaded Patch Panel
Attribute | Details |
|---|---|
Model Name/Number | NPP‑C61BLK481 (Cat6 UTP 48-Port Loaded Patch Panel) |
Cable Category | Cat6 UTP |
Loaded / Unloaded | Fully Loaded (48 RJ45 jacks) |
Rack Units (U) | 1U (standard 19″ rack mount) |
Panel Material | SPCC steel, 1.6 mm thick, Black (RAL 9005) painted |
RJ45 Jack Module | PBT + Glass Fiber (UL94V‑0) |
Gold Contact Plating | 50 µ″ gold over phosphor bronze on plug contact area |
IDC (Back terminations) | PC housing, phosphor bronze/tin-plated terminals; supports 22–26 AWG stranded or solid |
Punch-down Compatibility | Compatible with both 110 and Krone punch-down tools |
Transmission Performance | Meets Cat6 ANSI/TIA 568-C.2 standard, rated to 250 MHz |
Wiring Schemes Supported | T568A and T568B (label stripes included) |
Insertion Force | Maximum 20 N per IEC 60603‑7‑4 |
Retention Strength | Minimum 7.7 kg between jack and plug |
Mating Durability | ≥ 750 mating cycles |
Operating Temperature | -10°C to +60°C |
Cable Management | Optional cable management bar available |
Labeling | Transparent ID plate + color-coded strips for port ID |
General
- Ports Quantity48
