D-LINK 8-Port Gigabit Smart Managed (DGS-F1210-10MP)
8 Ports: 8 Gigabit Ethernet ports for fast and reliable connectivity
PoE Support: 8 Power over Ethernet (PoE) ports for powering devices like IP cameras
Smart Managed: Offers basic network management features for easier control
Compact & Efficient: Ideal for small to medium-sized businesses with network optimization needs
Feature | Description |
|---|---|
Model | D-Link DGS-F1210-10MP |
Ports | 8 Gigabit Ethernet Ports + 2 Gigabit SFP Ports |
PoE Support | 8 ports with 802.3af/at PoE+ (Power over Ethernet), providing up to 140W total PoE power budget |
Managed Type | Smart Managed (Web-based Management Interface) |
Layer | Layer 2 (Switching) |
Switching Capacity | 20 Gbps (Full Duplex) |
Forwarding Rate | 14.88 Million Packets per Second (Mpps) |
VLAN Support | Supports up to 256 VLANs with IEEE 802.1Q VLAN tagging |
QoS (Quality of Service) | 802.1p, DiffServ, and traffic prioritization for effective bandwidth management |
Link Aggregation | Supports Link Aggregation (LACP - IEEE 802.3ad) for network redundancy and improved throughput |
Security Features | - MAC Address Filtering - 802.1X Port Security - Storm Control (Broadcast/Multicast/Unicast) - Access Control Lists (ACLs) |
Redundancy and Reliability | - Spanning Tree Protocol (STP) - Rapid Spanning Tree Protocol (RSTP) - Loopback Detection - Storm Control |
SFP Ports | 2 Gigabit SFP Ports for fiber uplinks |
Power Supply | Internal Power Supply: 100-240V AC, 50/60Hz |
Management Interface | Web-based GUI, SNMP v1/v2/v3, Telnet, and CLI for easy network management and configuration |
Energy Efficiency | - IEEE 802.3az Energy Efficient Ethernet (EEE) - D-Link Green technology to optimize power consumption when devices are inactive |
Cooling | Fanless design for silent operation |
Dimensions (H x W x D) | 43 mm x 180 mm x 105 mm |
Weight | 0.57 kg (1.26 lbs) |
Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Warranty | 5-Year Limited Warranty |
Additional Features | - Diagnostic LEDs for port status and monitoring - DHCP Snooping, Dynamic ARP Inspection (DAI) for security - Easy PoE power management through the web interface |
