TP-Link VIGI 4MP Outdoor Network Camera-InSight S345ZI
Camera Resolution | 4 MP |
Brand | TP Link |
Model Number | VIGI S345ZI |
Camera Technology | Bullet Camera |
Image Sensor | 1/2.9" Progressive Scan CMOS |
Focal Length | 2.7-13.5 mm (5X Optical Zoom) |
Aperture | F1.6 |
Day/Night Mechanism | IR Cut Filter |
Max. Resolution | 2688 x 1520 |
Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
Lens Mount | M14 |
Camera Specifications
Category | Specification |
|---|---|
Image Sensor | 1/2.9” Progressive Scan CMOS |
Shutter Speed | 1/3 to 1/10,000 s |
Slow Shutter | Yes |
Minimum Illumination | 0.005 Lux; 0 Lux with IR Light |
Day/Night Mechanism | IR Cut Filter |
Day/Night Switch | Unified / Scheduled / Auto |
Lens Specifications
Type | Motorized Varifocal Lens |
|---|---|
Focal Length | 2.7 – 13.5 mm (5× Optical Zoom) |
Aperture | F1.6 |
Lens Mount | Φ14 |
Field of View (FOV)
Zoom Range | Horizontal FOV | Vertical FOV | Diagonal FOV |
|---|---|---|---|
2.7–13.5 mm | 29.6° – 102.0° | 16.8° – 53.8° | 34.1° – 122.8° |
DORI Distance
Zoom Range | Detect | Observe | Recognize | Identify |
|---|---|---|---|---|
2.7–13.5 mm | 66–207 m (217–579 ft) | 28–86 m (92–282 ft) | 13–41 m (43–135 ft) | 7–21 m (23–69 ft) |
Angle Adjustment (Manual)
Pan | 0° to 360° |
|---|---|
Tilt | 0° to 90° |
Rotation | 0° to 360° |
Illuminator
IR LED | Quantity: 4<br>Range: 60 m (197 ft)<br>Wavelength: 850 nm |
|---|---|
Illuminator Control | Auto / Scheduled / Always On / Always Off |
Video
| Max. Resolution | 2688 × 1520 (≈ 4 MP) |
General
- TypesIP
- Placement SupportedOutdoor
- Case TypeBullet
- Megapixel (Approx.)4 MP
- Mounting TypeCeiling/Wall
- AudioBuilt-ln Microphone
- Connectivity TechnologyWired
- Power Over EthernetYes
