D-Link DGS-1024D, Unmanaged 24 Port, DGS-1024D

General

Type

Unmanaged

Installation

Plug and Play

Model

DGS-1024D

Part Number

DGS-1024D

Management Protocols

CSMA/CD

In the Box

Switch, Power Adapter, Product Information Document

Brand

D-Link

Operating Conditions

Operational Humidity

5% to 90% (non-condensing)

Operational Temperature

0°C to 40°C

Storage Temperature

-10°C to 55°C

Power

Power Adapter Input

100-240 V AC, 50-60 Hz

Power Consumption

26.7 W

System Requirements

Hardware Memory

Packet Buffer Memory: 500 KB per device

Network Ports

Number of Ethernet Ports

24

Speed

10/100/1000 Mbps

Supported Protocols

Supported Protocols

IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p

Network Features

Forward Rate

10 Mbps: 14,880 pps
100 Mbps: 148,810 pps
1000 Mbps: 1,488,100 pps

Bandwidth

48 Gbps

MAC Address Database

8000 entries

MTBF (Mean Time Between Failures)

784,286 hours

Indicators

LEDs

System Power, Link, Speed, and Activity indicators per port

Additional Features

Certifications & Compliance

CSA: NRTL/C, Emissions: FCC Class A / CE Class A, Environmental: RoHS Compliant

Dimensions

Height

44 mm

Width

240 mm

Depth

180 mm

Weight

1800 g (1.8 kg)
